High accuracy 0.065% accuracy for all calibrated spans is the standard feature for pressure transmitter covering 1.3 to 10000kPa, 0.04% accuracy as option. The compositive monocrystalline piezoresistive sensor assures this accuracy for all elevated or suppressed calibration ranges without additional adjustment.
Minimum environmental influence The Advanced Cell design, which protects the pressure sensor against changes in temperature, static pressure, and overpressure substantially reduces total measurement error in actual field applications.
Application flexibility Various options that render the CXT suitable for almost any process applications include: – Full range of hazardous area approvals – Built-in RFI filter and lightning arrester – 5-digit LCD meter with engineering unit – Stainless steel electronics housing – Wide selection of anticorrosion materials
Span, range Working pressure Span (kPa) Range (URL) Over range Type (MPa) Min. Max. KPa MPa SKG 00 -0.04~0.4 1.6 40 40 0.2 SKG 01 -0.1~0.25 2.5 250 250 0.75 SKG 02 -0.1~0.8 8 800 800 2.4 SKG 03 -0.1~3 30 3000 3000 9 SKG 04 -0.1~10 100 10000 10000 15 Note: LRL= Lower Range Limit; URL= Upper Range Limit. To minimize environmental influence, span should be greater than 1/40 of the max. span in most applications.
Process temperature, Lower range limit Fill Fluid 13th digit code Process temperature Lower range limit Silicone oil Y, G (-40~100)°C 2.7kPa abs Fluorinated oil W, A, D (-20~80)°C Atmospheric pressure
Performance Specifications for Linear Output (Zero-based calibrated ranges, reference conditions, silicone oil fill, 316L SST isolating diaphragms and 4 to 20mA analog output in linear mode.)
Accuracy rating (including linearity, hysteresis, and repeatability) For spans greater than 1/10 of URL: ±0.065% of span or ±0.04% of span (21st digit: H) Temperature effect Effect per 28°C change between the limits of -40°C and +85°C Over range effect Zero shift: ±0.2% of URL for any over range to maximum limit Stability ±0.1% of upper range limit (URL) for 10 years. Mounting position effect Zero shift: less than 0.12kPa for a 10° tilt in any place (0.24kPa for 13th digit code "W","D","A").No effect on span. This error can be corrected by adjusting zero.
Physical Specifications Process-wetted parts material Material code (7th digit in "Ordering Code") Process cover Process-wetted body Diaphragm Wetted sensor body V CF8M 316L SST 316 SST W CF8M Hastelloy-C 316 SST J CF8M 316L SST + Au coating 316 SST H CF8M Hastelloy-C Hastelloy-C P CF8M 316L SST+ PTFE coating 316L SST T CF8M Tantalum 316 SST Non-wetted parts material Electronics housing Low copper die-cast aluminum alloy finished with polyester coating (silver), or CF8M, as specified. Electronics housing cover Low copper die-cast aluminum alloy finished with polyester coating (atrovirens), or CF8M, as specified. Environmental protection IEC IP67 Mass (weight) Transmitter approximately 3.1 to 3.6kg without options Electrical connections ½-14NPT or M20×1.5 conduit, as specified. External terminal M4 screw Process connections ¼-18NPT Mounting On 50A(2B) pipe using mounting bracket, direct wall mounting or direct process mounting. Transmission unit position The transmission unit can be turned at 90° or 180°in the clockwise or counterclockwise direction.
Sample Cost,The cost will be returned after placing an order
Sample Lead Time
T/T, LC at sight,west union,paypal
carton package with protection material
Ningbo or Shanghai
Q: Are you a manufacture or a trading company?
A: We are a 20-year-manufacturer engaged in the field of cleaning products, and we have got the permit of import and export as well.
Q: Where is your factory located? How can I visit there?
A: Our factory is located in Hangzhou, China. 25 Minutes by car far away from Xiaoshan Airport.
Q: How can I get the differential pressure sensor pad samples? What's the lead time?
A: Samples could be sent within one week, the lead time is 35-45 days..
Q: Do you provide differential pressure sensor pad ODM/OEM service?
A: OEM/ODM is welcome, there are 25 persons in our R&D team, and customized colours is optional. From the concept to finished goods, we do all (design, prototype reviewing, tooling and production) in the factory.
