SUPCON CXT-SKE differential pressure 4-20ma level transmitter

FOB Reference Price:Get Latest Price
US $699-1,499 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
SUPCON
Model Number:
SKE Level Transmitter
Service:
Liquid, gas and vapor applications
OEM,ODM::
Welcome
EMC Conformity:
EMC(2004/1085/EC)
Output:
4~20mA with Hart
Power supply:
(10.5~45)VDC
Failure Mode Alarm:
"Output Hold""Output Overscale""Output Underscale"
Sample Lead Time::
7-15 days
Finish::
Printing
Advantage::
High accuracy and stability
Product Name:
level transmitter
Supply Ability
Supply Ability:
60000 Piece/Pieces per Year level transmitter
Packaging & Delivery
Packaging Details
Standard Export Packing
Port
ShangHai/NingBo
Lead Time :
Quantity(Pieces) 1 - 10 >10
Est. Time(day) 15 To be negotiated
Product Description

Product Application

The CXT smart pressure transmitter utilizes a unique compositive monocrystalline piezoresistive sensor and the advanced cell design with state-of-the-art microprocessor technology, up to 0.035% accuracy for all calibrated spans, ±0.1% of upper range limit (URL) for 10 years, has a longer service life, the use of safe and reliable and convenient.

It is designed for various industries including Petroleum, Power, Chemical, Metallurgy, Pharmacy, Light industry and more.

SPECIFICATIONS

General Specification
Service
Liquid, gas and vapor applications
Output
4~20mA with Hart
Power Supply
(10.5~45)VDC





Main performance parameters
Accuracy
±0.05%
Stability
±0.1% of upper range limit (URL) for 10 years.
Electrical connections
M20*1.5(M),1/2-14NPT,customer
Diaphragm material
SS316L, Hastelloy C
Pressure range
(0.2~6)kPa, (0.4~40)kPa, (2.5~250)kPa, (8~800)kPa, (30~3000)kPa
Environmental protection
IEC IP67



Physical Specifications
Indicator
An optional 5-digit LCD meter with enginerring unit is also available.
EMC Conformity
EMC(2004/108/EC)
Process connections
1/4-18NPT
Weight
3.1 to 3.6kg without options

Main Features

1) High Accuracy:  0.05%.

2) Stability:  ±0.1%  of upper range limit (URL) for 10 years.


Core parts


Welcome Customization

Double Flange Gold-plated Diaphragm

Long Diaphragm Extension

Depth of insert tube is up to 450mm


Small Flange Long Capillary


Exhibition
Appalication
Certifications
Our Company

A Leading Automation Supplier


Founded in March 1993, SUPCON is one of China's leading providers of automation and information technology, products and solutions. SUPCON has grown rapidly on the back of cutting-edge systems for the development of innovative and solutions are applied in over 35 countries and regions worldwide.

SUPCON has strong technical force, well-processing equipment, a complete quality management system.
Using advanced production technology and integrated quality management system to ensure the quality of our products.
And we have got many Certifications, including ISO 9001 AND 14,001 certification, CE, SIL and so on.


                        SMT

                   Coating


                   Calibrating
