Input-Type HD5500 series Intrinsic Isolated Safety Barrier

FOB Reference Price:Get Latest Price
US $50-80 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
SUPCON
Model Number:
HD5500
Output signal:
4~20mA
Type:
PT100,J, K, T, E, R, S, B or N
Supply Ability
Supply Ability:
5000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
320*240*250mm/ctn 20pcs/ctn
Port
HANGZHOU
Lead Time :
Shipped in 10 days after payment
Product Description

Introduction



HD5500 series isolated barriers are designed explicitly according to latest national standard for protection of electrical signals located in hazardous areas.



Installed in safe areas, HD5500 series Isolated barriers work in company with intrinsically safe instruments located in hazardous areas to guarantee a totally IS explosion protection system. With the inside signal transfer module, HD5500 series isolated barriers can also play the roles of  RTD temperature transmitter, thermocouple temperature transmitter and mV transmitter, as well as repeater power supply, solenoid driver and so on.



Features

  • No high-integrity earth needed

HD5500 series Isolated barriers need no dedicated ground and consequently eliminate the inherent interference of

ground loop.

  • Full input/output/power supply isolation

Full 3-port isolation between the input, output and power supply circuits achieves highly floating systems for the pursuit of

extraordinary resistibility to complicated electromagnetic interference from industrial environment.

  • High performance components

High performance components are widely adopted for optimal signal integrity, taking into account both high accuracy and

low drift of full range.

  • Compact modular design

With compact modular design, HD5500 series isolated barriers provide wide application range in the minimum space.

  • Standard DIN-rail mounting and PLUG & PLAY terminals

Standard DIN rail mounting format ensures convenient and steady installation, while application of PLUG & P LAY

connector ensures the convenience of maintenance.
